The Ultimate Guide to Empirical Lab’s FATSO Tape Simulator

How a popular modern tape sim and compressor adds thick saturation, punch, and warmth to your whole mix.

Today we’re going deep on one of my favorite UAD plug-ins, the Empirical Labs FATSO Tape Simulator.

Now available as a UAD Native plug-in, the FATSO is more than just a tape sim. It’s also an analog saturator, transient-shaper, high-frequency softener, and transformer-style harmonic generator. It also works as an excellent distortion tool when pushed.

Used by legendary engineers with credits ranging from Willie Nelson to AC/DC, the FATSO UAD plug-in is the only authentic emulation endorsed by its designer, Dave Derr. Here, we break down everything you need to know.

Understanding the Input Control

The Input controls on the FATSO are where a lot of the plug-in’s character comes from.

When you drive the input, the discrete distortion circuits flatten the tops and bottoms of the waveform. This generates third-order harmonics. Second-order harmonics join in once the compressor starts working.

The FATSO converts peak energy into harmonics, and our ears read those harmonics as weight and loudness. The decibel level stays put while the perceived loudness goes up. This means you vocals get thicker, bass gets more present, drum buses lock together, and mixes get louder without higher peaks.

THD Meters: How Much Grunge Do You Want?

The THD LEDs display how hard you're driving the FATSO. Yellow 0 VU means roughly 1% THD. Red Pinned means roughly 5% or more.

Around 1%, you add real harmonic character without hearing obvious distortion. When you push past that, things get aggressive fast.

Adding the right amount of character depends on the source. On a full mix, 10% can sound ridiculous. On a kick, bass, vocal, synth, or guitar, it can sound incredible.

The FATSO adds perceived loudness and density without raising peak levels.

Using the Warmth Circuit

The FATSO's Warmth circuit is designed to emulate the high-frequency softening you get from analog tape.

As you increase Warmth, bright high-frequency content and transients are attenuated. But the time constants are extremely fast. This means that when a bright transient spike hits, those high frequencies get pushed down almost immediately. Imagine a compressor that’s only allowed to compress the top end. This effect can be really useful on things like cymbals, vocals, acoustic guitars, bright synths, harsh room mics, or even full mixes.

Enhancing Lows with the Transformer Circuit

Next up is the Transformer circuit. This is probably one of the coolest functions of this plug-in.  It’s designed to add the kind of low-frequency harmonic behavior associated with analog tape and transformer coloration.

This one is really cool because the psychoacoustic result can be a little counterintuitive. You’re not necessarily getting more bass. Instead, the extreme low end is harmonically altered, meaning peaks can actually become lower, while the low end can sound louder.

Why is this? It's because you’re generating harmonics that make the fundamental information easier to perceive. This can be especially useful on smaller playback systems.

For example, you might have a bass guitar with a ton of energy down at 50 Hz that sounds amazing on a giant studio system, but basically disappears on laptop speakers. The transistor circuit creates harmonic information higher up the spectrum that helps your brain perceive that low-frequency information.

The original Empirical Labs FATSO ("Full Analog Tape Simulator and Optimizer") was designed by Dave Derr and combined compression, harmonic saturation, and tape-style softening to add warmth and punch. A hallmark effect of the original hardware is its ability to increase perceived low end and make mixes translate better on small speakers.

Understanding the Four Compressors

Buss: This setting gives you roughly 2:1 style compression curve with slow attack, fast release, and a very soft knee.

Typically, you’re looking at around 1 to 4 dB of gain reduction, which can be the sweet spot.You can hit it harder, but once you’re getting into 5 dB or more of gain reduction, you’re no longer gently hitting the bus.

The slower attack lets transients through, while the compressor gently controls the overall movement of the signal.

This makes Buss a really natural choice for drum buses, mix buses, instrument groups, stereo synths, and anything you want to feel more cohesive.

General Purpose: This is a nice "all-around compressor" setting with a medium attack and a slower release.

The slower release is important because it helps maintain a consistent RMS level without constantly pulling the signal forward.

It’s a really useful choice when you want consistency without a ton of obvious compression movement. Vocals, bass, guitars, keys, even individual drum tracks can all work here.

There is no fixed release time for the compression. The FATSO is always changing how it lets go.

Tracking: This mode is essentially an 1176-style compressor, so it gives you a more assertive compression character.

Tracking is great for vocals and instruments, but also useful during mixing. If you want something to feel more controlled, more forward, and more energetic, it's a great place to start.

Spank: This is based on a radical limiter-style compressor designed around the aggressive squeeze of older talkback compressors from the 1970s and ’80s.

Compared to the other modes, Spank is much more likely to color your sound. You can use it to squash and energize drums and make room mics more explosive, bring a vocal more forward, or add excitement to an otherwise boring keyboard sound.

How it All Works Together

With the FATSO, all the sounds we love about tape and saturation come together at the same time. And what makes the plug-in special is that they’re interacting with each other, rather than working in isolation.

Your Input level affects how hard you’re driving the distortion circuits. The compressor changes the level and dynamics going into the rest of the processing. Warmth is reacting specifically to high-frequency content. The transistor is changing the harmonic structure of the low end. And the compressor mode determines how aggressively the dynamics are controlled.

Two FATSO presets with identical Warmth and Tranny settings can sound completely different depending on how hard you’re hitting the Input, and which compressor mode you’re using. This is why simply copying settings from one track to another isn’t necessarily going to get you the same result.

Final Thoughts

So, what is the FATSO? And who is it for?

Beyond a single effect, the FATSO brings together all the positive things we associate with analog recording: harmonic distortion, soft clipping, high-frequency softening, low-frequency harmonic enhancement, and several different compression curves.

With the FATSO, it's not about finding one magic preset. Instead , it’s about understanding how hard you’re hitting it, what part of the frequency spectrum you’re trying to affect, and which compression behavior fits the source. You can use it subtly to make a track feel a little more cohesive, or you can absolutely destroy something with it.

Once you understand the details, this wonderful modern processor stops being a mysterious “analog magic” box, and becomes a powerful sound-design tool that's useful for nearly any mix.

– Brit Rogers

---

Related Articles

• A Guide to Distortion for Home Recordists
• Best UAD Plug-Ins of the Year
• Seven UAD Plug-Ins to Try Today
• Best Compressor Plug-Ins in UAD Spark Studio

Frequently Asked Questions

What does FATSO stand for?

FATSO stands for Full Analog Tape Simulator and Optimizer, and the Empirical Labs FATSO Tape Simulator plug-in models the hardware unit Empirical Labs founder Dave Derr designed. Derr built the FATSO to capture the musical behavior of multiple compressors, Class A electronics, and magnetic tape in one box. It became a fixture in professional studios, used by engineers with credits ranging from Willie Nelson and Bonnie Raitt to AC/DC, Pearl Jam, and Soundgarden.

What's the difference between FATSO Jr. and FATSO Sr.?

The Empirical Labs FATSO Tape Simulator includes two plug-ins: FATSO Jr, which captures the classic hardware's controls and tone, and FATSO Sr, which adds custom features designed by Dave Derr that go beyond the original hardware. FATSO Sr gives you variable transformer saturation, sidechain filtering, and deeper compression parameters including Threshold, Attack, and Release. Reach for Jr when you want those iconic tones fast, and Sr when you want to fine-tune exactly how the compression grabs and how much transformer color comes through.

What are the FATSO's four compression modes?

The Empirical Labs FATSO Tape Simulator offers four compression modes: Buss, G.P., Tracking, and Spank. Buss is a gentle 2:1 ratio with a soft knee for mix glue, G.P. is a transparent workhorse that holds a steady level, and Tracking is an 1176-style compressor for vocals and instruments. Spank is a radical limiter modeled on the squeeze of '70s console talkback compressors, and you can stack it on top of another mode when a track needs extra grab.

How does the FATSO tame harsh high frequencies?

The Empirical Labs FATSO Tape Simulator tames harsh highs with its Warmth circuit, which softens the top end the way analog tape naturally does. Because it works alongside the compression and saturation in the same insert, you can control dynamics, add harmonic thickness, and smooth out brightness all at once. It's especially useful for calming sibilant vocals, bright cymbals, and edgy electric guitars.

Does the FATSO plug-in sound like the original hardware?

Yes, the Empirical Labs FATSO Tape Simulator was developed in collaboration with Empirical Labs founder Dave Derr, who scrutinized it for accuracy against the original hardware. It captures both the hardware's subtle harmonic coloration and its extreme squeeze, including how the input drive, transformer, Warmth, and compression stages interact. The native version delivers the same sound as the UAD DSP version that Apollo owners have used for years.
